Primer: Printed Circuit Boards
| By: | Andrew Argyle |
| Publisher: | O'Reilly Media, Inc. |
| Print ISBN: | 9780596808594 |
| eText ISBN: | 9781449391829 |
| Edition: | 0 |
| Format: | Page Fidelity |
eBook Features
Instant Access
Purchase and read your book immediately
Read Offline
Access your eTextbook anytime and anywhere
Study Tools
Built-in study tools like highlights and more
Read Aloud
Listen and follow along as Bookshelf reads to you
Step-by-step instructions for making your own PCBs at home.
Making your own printed circuit board (PCB) might seem a daunting task, but once you master the steps, it's easy to attain professional-looking results.
Printed circuit boards, which connect chips and other components, are what make almost all modern electronic devices possible. PCBs are made from sheets of fiberglass clad with copper, usually in multiplelayers. Cut a computer motherboard in two, for instance, and you'll often see five or more differently patterned layers. Making boards at home is relatively easy, but limited to one- or two-layer designs. Here's how to create a one-layer board for a blinking LED circuit. For PCBs, this exercise is the equivalent of a beginner's "Hello World" program in software.
This primer first appeared in Make: Technology on Your Time Volume 02.
